1500 Single-Ram BOP

Monitor high-pressure applications and achieve greater well control with our blowout preventers.

  • Description Description
  • Ruler Specifications
Description

We provide an extensive portfolio of blowout preventers for well control and monitoring high-pressure applications with various ram options.

Features/Benefits

  • Caps have hammer lugs and ACME threads for fast removal and replacement (ACME threads eliminate cross-threading)
  • Cap with internal threads protected from the environment
  • Lugless cap option for installation on API flanged bonnets
  • Blowout-proof ram screw
  • Full opening
  • Reinforced ram block reduces extrusion
  • Cap O-ring provides reliable, pressure-tight seal
Specifications

1500 Single-Ram BOP

Sizes available

2 in.

2.5 in.

3 in. LP

Vertical bore

1.975 in.

2.560 in.

2.970 in.

Working pressure

1,500 psi

Body and cap material

Ductile iron*

Ram screw and packing gland

Carbon steel**

Ram size options

Blind, ⅝1 in., 1.125 in., 1.250 in., 1.500 in., 1.750 in.

Ram screw packing ring

Acrylic braided PTFE

Connection

Male × female thread

Optional flange connections

N/A

Height

9.5 in.

Weight

43 lb

Width (rams open)

20 in.

Handles

Optional


Note: 150H and 200P rams are not interchangeable. Additionally, they are "directional" due to the internal reinforcement plate. Always install with "THIS SIDE UP" sticker facing up.

*Corrosion-resistant materials and coatings are available; contact customer service.

**NACE stainless steel optional





Ram Materials

  NBR Compound C HSN FKM AFLAS
Maximum temperature 250 °F (121 °C) 300 °F (149 °C) 325 °F (163 °C) 400 °F (204 °C) 450 °F (232 °C)
Maximum H2S 2% 2% 10% 20% 35%
Maximum CO2 NR 10% 20% 5% 15%
