Register here Sign inReAct Tracer Valve
As an integral part of the lower completion string, our ReAct Tracer Valve introduces a chemical tracer into the production fluid.
-
Description
-
Specifications
-
Resources
The ReAct™ Tracer Valve (RTV) introduces a chemical tracer into the production fluid upon expiration of a preprogrammed time delay. It is normally installed as an integral part of the lower completion string in either the motherbore and/or lateral section of the well.
Installation of the ReAct™ Tracer Valve can provide effective reservoir and well surveillance information without the normal risk and cost associations with intervention operations or intelligent completion hardware.A selection of tracer strips can be installed into the ReAct Tracer Valve for gradual dispersal, and/or a tracer fluid can be stored in the ReAct Tracer Valve's tracer chamber for a larger chemical fingerprint over a shorter time frame. The sealed tracer chamber is opened via the ReAct Tracer Valve's ReAct electronic actuation system, which features two ReAct electronic units that operate independent of each other for full redundancy. Following a delay of up to 150 days, the ReAct electronic actuation system allows well pressure to flood an atmospheric chamber and provide more than 30,000 lb of opening force to shift a containment sleeve to the open position. In doing so, the well flow is permitted to flow through the tracer chamber via the machined flow slots, driving the tracer into the wellbore fluids.
Features
- Field-proven electronics
- Delayed activation of up to 150 days
- Two independent electronic actuation systems
- Sealed tracer chamber
- Flow slots to drive tracer
Benefits
- Reducing cost and risk
- Full control on tracer introduction
- Reservoir and wellbore surveillance
Applications
- Well clean-up monitoring
- Long-term inflow monitoring
- Water breakthrough location
- Reservoir flow
- Cross-flow evaluation
ReAct Tracer Valve Specifications
| Tool size | 6.625 in. | 5.500 in. |
| End Connections | 6⅝-in. OD premium | 5½-in. OD premium |
| Material | AISI 420 Mod 13% Cr | AISI 420 Mod 13% Cr |
| OD | 7.675 in. | 6.200 in. |
| ID | 3.870 in. | 2.875 in. |
| Length | 81.0 in. | 81.0 in. |
| Tensile rating | 465,000 lb | 408,000 lb |
| Working pressure rating | 5,000 psi | 5,000 psi |
| Temperature rating | 135 °C | 135 °C |
| Time delay | Programmable up to 365 days | Programmable up to 365 days |
Other sizes and ratings are available upon request
