Sentinel WRSV-5/10E Safety Valve

The WRSV-5/10E is a wireline retrievable safety valve rated for working pressures of 5,000 psi (34 474 kPa) or 10,000 psi (68 948 kPa) and temperatures up to 300 °F (149 °C).

Render of  subsurface valve
  • Description Description
  • Ruler Specifications
  • Resources Resources

The WRSV-5/10E is a wireline retrievable safety valve (WRSV) rated for working pressures of either 5,000 psi (34 474 psi) or 10,000 psi (68 948 kPa) and temperatures up to 300 °F (149 °C). The WRSV compact design uses a metal-to-metal flapper closure seal and an optional self-equalizing flapper to provide 100% well containment when closed.

The WRSV is primarily used when a tubing retrievable safety valve (TRSV) cannot be used because of dimensional constraints in the well completion. It also functions as a backup, redundant safety valve to nonfunctioning TRSVs. Downhole-specific material selection options are available for both corrosive and erosive environments.

The WRSV-5/10E is connected to a downhole lock and landed in either a dedicated hydraulic landing nipple or inside a TRSV where hydraulic communication has been established. The WRSV operates with a surface-controlled emergency shutdown (ESD) system that supplies hydraulic control pressure to actuate the WRSV’s flow tube to open and close the flapper. The WRSV is a fail-safe, normally closed valve that will protect production installations from uncontrolled flow if wellhead equipment is damaged in a catastrophic event. After shut-ins, the optional self-equalizing flapper design facilitates a rapid return to production, reducing operational downtime.

The WRSV is tested/certified to API-14A-V1 and manufactured in accordance with ISO-9001:2015 standards. Materials selection options are based on NACE MR-0175 compliance. We provide global service support for installation, field repair, and maintenance from over 28 service centers worldwide.



  • Field redressable
  • Compact design
  • Standard self-equalizing
  • Configurable to special applications

Optional features

  • Non-equalizing
  • H2S/CO2 trim
  • Shallow setting depth


  • Serviceable by wireline
  • Easy to install and operate


  • Oil and gas wells
  • Up to 2,000-ft setting depth
  • Shut-in pressure up to 10,000 psi
  • Temperatures from 40 to 300 °F
  • Both sweet and sour service

Sentinel WRSV-5/10E Specifications

Tubing size

2.875 in. (73.03 mm)

3.500 in. (88.90 mm)

Max. OD (metal)

2.278 in. (57.86 mm)

2.773 in. (70.43 mm)

Nipple bore diameter

2.313 in. (58.75 mm)

2.813 in. (71.45 mm)

Min. ID

1.100 in. (27.94 mm)

1.560 in. (39.62 mm)

Working pressure

5,000/10,000 psi (34 474/68 948 kPa)

  • WRSV-5/10E Safety Valve (SCSSV) Data Sheet
